J010AS 10PHON Junior 1-10x24 Riflescope

30mm Monotube, Fully-Multi Coated, Etched Glass MIL Reticle llluminated, 1/10 MIL Turret Lock Feature, Wide F.O.V

Contact
Describe
10PHON Junior 1-10x24 Riflescope
Item NoJ010AS
Magnification1-10x
Objective Lens Dia24mm
Maintube diameter30mm
ReticleEtched Glass MIL Reticle llluminated
Diopter range +/- 2
Eye relief101.2mm / 3.984 inch
Click Value1/10 MIL
Elevation Range @100 yards≥ 100MOA
Windage Range @100 yards≥ 100MOA
Parallax Compensation100yds
Fast focus eyepieceYes
Sealing gas usedNitrogen
Clear aperture min magnification16mm / 0.6299 inch
Clear aperture max magnification24mm / 0.9448 inch
Eff. exit pupil diameter @  min. magnification ± 3 %16
Eff. exit pupil diameter @  max. magnification ± 3 %2.4
Maximum resolution in Arc. Second (min. Magnification)11
Maximum resolution in Arc. Second (max. Magnification)7
Range of Function temperature (Unit can still be operated)'-25°C/+55°C
Storage temperature'-40C to +85C
Range of Dioptric compensation +/- dpt2
Permissible backlash Dioptric Compensation<0.25dpt
Objective field of view @ min magnification (ft @100yds)118.2
Objective field of view @ max magnification (ft@100yds)11.8
Change of impact point after change of magnification 1.5MOA
Straightening  of the Reticle± 2 °
CoatingFMC
Length276mm / 10.866 inch
Weight593g
